Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
Page 126/179 © Woodward
Engine Delayed Monitoring Of The Analog Inputs
Parameter 243
Ana.in 12345678
SV.del. NNNNNYNN
Analog inputs; engine delayed monitoring Y/N
The analog inputs may be disabled until the engine has reached the configured fir-
ing speed (Parameter 272). This parameter specifies which analog inputs are to be
co
nstantly enabled or disabled until firing speed has been achieved by configuring
a "Y" or an "N" below the input number.
Y ................... Monitoring of the analog input is enabled after firing speed has been
reached (the green LED "Protection" illuminates).
N ................... The analog input is always monitored.
Note: If the controller is equipped with 5 or more analog inputs, the screen for this
parameter will display 8 inputs. If the control is equipped with 4 or less analog in-
puts this parameter screen will display 4 inputs. If the control is equipped with
fewer inputs than are displayed on the screen, only changes made to the valid in-
puts will have any effect on the control.
Analog Inputs Selectable as Control Inputs
Parameter 244
Ana.in 12345678
control NNNNNNNN
Analog input as control input J/N
This parameter defines if specific analog inputs operate as control inputs or not.
Y ................... The analog input operates as control input: The analog value is dis-
played and the configured relays are enabled when the configured
limits has been reached. However, an alarm will not be issued and a
message will not be transmitted on the CAN bus.
(A wire break will not effect the behavior of the control)
N ................... The analog input operates as described for the above settings.
Note: If the controller is equipped with 5 or more analog inputs, the screen for this
parameter will display 8 inputs. If the control is equipped with 4 or less analog in-
puts this parameter screen will display 4 inputs. If the control is equipped with
fewer inputs than are displayed on the screen, only changes made to the valid in-
puts will have any effect on the control.
