Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
© Woodward Page 147/179
Func-
tion
Output Value Input of the two limit values
11
Analog input [T1] [°C] or
[°F] or
freely scaleable
0% Lower measured value
e.g. 0000 corresponds to 000 °C
at temperature input
100% Upper measuring value
e.g. 0255 corresponds to 255 °C
at temperature input
0% Lower measured value e.g. 0000
corresponds to 00.0 bar oil pressure
100% Upper measured value e.g. 0100
corresponds to 10.0 bar oil pressure
12
Analog input [T2] [°C] or
[°F] or
freely scaleable
13
Analog input [T3] [°C] or
[°F] or
freely scaleable
14
Analog input [T4] [°C] or
[°F] or
freely scaleable
15
Analog input [T5] [°C] or
[°F] or
freely scaleable
16
Analog input [T6] [Bar] or
[PSI] or
freely scaleable
17
Analog input [T7] [Bar] or
[PSI] or
freely scaleable
18
--free--
[°C] or
[°F] or
freely scaleable
19
Actual mains interchange (im-
port/export) real power
[kW] 0% lower power
e.g. -0800 kW
100% upper power
e.g. 0800 kW
20
Mains apparent current in L1 [A] 0% Lower current output
e.g. 0000 A
100% Upper current output
e.g. 500 A
21
Mains power factor ϕ
[e. g. (-070 to +080) /100]
(Definition at end of Table)
[dimension-
less]
0% Lower interval to power factor ϕ=1
e.g. -0030 corresponds to k0,70
100% Upper interval to power factor ϕ=1
e.g. 0030 corresponds to i0,70
22
Actual mains reactive power [kvar] 0% capacitive reactive power (negative) e.g. -0100 kvar
100% inductive reactive power (positive) e.g. +0100 kvar
23
--free--
24 Generator real power set point,
which is currently issued by the
ramp of the real power controller
(Parameter 75)
The actual value of the generator
real power is
issued in isolated
operation
[kW] 0% lower set point
e.g. 0000 kW
100% higher set point
e.g. 0800 kW
