Maintenance
Xerox Color 550/560 Printer
User Guide
271
Replacing the Charge Corotrons
Make sure the machine has stopped running, and open the Front Door.1.
Pull down the R1-R4 handle.2.
Raise the Release Handle.3.
Open the packaging for the new Charge Corotron and gently place the new Charge Corotron on a flat
surface near the machine.
4.
CAUTION:
Do not expose drum cartridges to direct sunlight or strong light from indoor fluorescent lighting for more
than two minutes. Image quality may deteriorate when the drum cartridges are exposed to light.
Open the Drum Drawer.5.
