Printer Specifications
Revised, 3rd Revision - Xerox Internal Use Only
Introduction
Electrical Specifications
Environmental Specifications
NOTE: Check that the printer is on a stable, non-vibrating surface. Advise the customer to use
care not to shake the printer excessively when loading media or closing the Front Door. During
operation, the ink is in liquid form and can spill from the Printhead reservoir resulting in output
defects.
Print Speed
First Print Output Time
First Print Output Time (FPOT) is defined as the time from when the engine receives a Start
signal in Ready state, until a single page is printed and delivered to the output tray.
From Ready State
From Non-Ready State
First Print Out Time includes the time required to print any maintenance pages (such as the
mud page) and a single customer page on A size media from Tray 2.
Table 3 Electrical Specifications
Characteristic Specifications
Primary Line Voltages • 90 - 140 VAC
• 180 - 264 VAC
Primary Line Voltages Frequency Range 47 - 63 Hz
Power Consumption at Rated Voltage Input •Warm-Up:
– Peak: 1250 W
– Typical: 930 W
• Printing: 250 W
• Idle: 104 W
• Power Saver: 45 W
– 38 W (110)
– 41 W (220)
In-rush Current • Less than 12A (110)
• Less than 6A (220)
Leakage Current Less than 3.5 mA
Table 4 Environmental Specifications
Characteristic Specifications
Operating Storage
Temperature
10
º
to 32
º
C (50º to 90º F) -30
º
to 60
º
C (-22º to 140º F)
Humidity 10% to 80% RH Non-Condensing 10% to 95% RH, non-condensing
Altitude 0 to 2,438 meters (8,000 ft.) 0 to 15,000 meters (49,212 ft.)
Acoustic Noise Operation Standby or Ready
Sound Power Level
(Bels)
7.0 B(A) 4.4 B(A)
Sound Pressure (Deci-
bels)
57.0 dB(A) 31.0 dB(A)
Table 5 Print Speed Specifications
Resolution/ Tray Simplex, A4 Paper Auto Duplex, A4 Paper
Tray 1
Fast Color (225x400) 13 ppm 13 ppm
Standard (300x450) 11 ppm 11 ppm
Enhanced (525x450) 10 ppm 9 ppm
Photo (525x2400) 6 ppm 6 ppm
PCL 600x400 Mode 10 ppm 9 ppm
PCL 600x600 Mode 6 ppm 6 ppm
Tray 2
Fast Color (225x400) 40 ppm 30 ppm
Standard (300x450) 30 ppm 25 ppm
Enhanced (525x450) 19 ppm 18 ppm
Photo (525x2400) 6 ppm 4 ppm
PCL 600x400 Mode 20 ppm 18 ppm
PCL 600x600 Mode 12 ppm 10 ppm
Table 6 Ready State
Resolution FPOT
Fast Color (225x400) 4 seconds or less
Standard (300x450) 7 seconds or less
Enhanced (525x450) 9 seconds or less
Photo (525x2400) 15 seconds or less
Table 7 Non-Ready State
Starting State FPOT
Off (cold) 12 minutes
Power Saver 2.5 minutes
Low Power (Standby) 30 seconds
Quiet Warm-Up 10 seconds
To Next Page
