ColorQube 8570/8870 Service Manual
Acronyms and Abbreviations
Introduction
Xerox Internal Use Only - Revised, 3rd Revision
Acronyms and Abbreviations
Table 1 Acronyms and Abbreviations
Acronyms/
Abbreviations
Description
A3 Paper size 297 millimeters (11.69 inches) x 420 millimeters (16.54 inches).
A4 Paper size 210 millimeters (8.27 inches) x 297 millimeters (11.69 inches).
A5 Paper size 148 millimeters (5.82 inches) x 210 millimeters (2.10 inches).
AC Alternating Current is type of current available at power source for printer.
AD Auto Duplex
A/D Analog to Digital refers to conversion of signal
AMPV Average Monthly Print Volume
ARP Address Resolution Protocol
ASIC Application Specific Integrated Circuit
ASSY Assembly
ATM Adobe Type Manager
ATVC Auto Transfer Voltage Control
BLK Black
BOOTP Bootstrap Protocol
BSD Block Schematic Diagram
BTM Bottom
C Degrees Celsius
CAM Camshaft
CCW Counterclock-Wise
CD Circuit Diagram
CD Compact Disc
CE CE mark is a mandatory conformity mark on products on a single market in
the European Economic Area (EEA).
CLT Clutch
CM Centimeter
CMD Command line interpreter
CMYK Cyan, Magenta, Yellow, Black
COMM Communication
CRU Customer Replaceable Unit
CSE Customer Service Engineer
CW Clockwise
CWIS CentreWare Internet Services
dB Decibel
DC Direct Current is type of power for machine components. Machine converts
AC power from power source to DC power.
DNS Domain Name System
DDNS Dynamic Domain Name System
DDR2 DIMM Double Data Rate Dual In-Line Memory Module
DHCP Dynamic Host Configuration Protocol
DIMM Dual In-line Memory Module
DM Drum Maintenance
DMM Digital Multimeter is generic name for meter that measures voltage, current,
or electrical resistance.
DMO Developing Markets Organization
DMU Drum Maintenance Unit
DNS Domain Main System
DPI Dots Per Inch
DPM Documents Per Minute
DR Drum
DRV Drive
Duplex 2-sided printing
EDOC Electronic Documentation
EEA European Economic Area
EC European Community
EEPROM Electronically Erasable Programmable Read-Only Memory
EMI Electromagnetic Interference
EOM End of Message
ER/ERR Error
ESD Electrostatic Discharge. A transfer of charge between bodies at different elec-
trostatic potential.
ETN Engine Tracking Number
ENV Environment
F Degrees Fahrenheit
FANG Fang is an ASIC found on the Main Board that deals with a lot of low-level
printer control operations. The FPGAs are the interface chips that allow the
separate boards to communicate to each other over the gray ribbon cables.
FCC Federal Communications Commission
FE Field Engineer
FFC FFC Cable
FIFO First In First Out
FPGA Field Pre-programmable Gate Array (Printhead interface and motor controller
for the printer)
FPOT First Print Output Time
FR/FRNT Front
FRU Field Replaceable Unit
FT Foot
FTP File Transfer Protocol
FTTR Fast Time To Ready
FUNC Function
