Xerox COLORQUBE 8570 Service Manual

October 2012
xxvi
ColorQube 8570/8870 Service Manual
Acronyms and Abbreviations
Revised, 3rd Revision - Xerox Internal Use Only
Introduction
FX Fuji-Xerox
G Gram
GB Giga Byte
GND Ground
GSM/ gsm Grams per Square Meter
GUI Graphical User Interface
HARN Harness
HCF High Capacity Feeder
HDD Hard Disk Drive
HFSI High Frequency Service Items
HTML Hyper Text Markup Language
HTTP Hyper Text Transfer Protocol
HUM Humidity
Hz Hertz (Cycles per second)
HW Hardware
IC Integrated Circuit
I/F Interface
IM Ink Melter
IME Image Marking Engine
IN Inches
IOT Image Output Terminal
IP Internet Protocol
IPA Isopropyl Alcohol
IPM/ ipm Images Per Minute
IPP Internet Printing Protocol
IPSec IP Security
IPV4 Internet Protocol Version 4
IPV6 Internet Protocol Version 6
IPX Internet Protocol eXchange
IQ Image Quality
IR InfraRed
IR Intelligent Ready
ISC Ink Stick Count
JPEG Joint Photographic Experts Group File Interchange Format
JS Jetstack
JSM Jet Substitution Mode
KB Kilo Byte
KG Kilogram
LAN Local Network Area
LBS Pounds
Table 1 Acronyms and Abbreviations
Acronyms/
Abbreviations
Description
LCD Liquid Crystal Display
LE Leading Edge
LED Light Emitting Diode
LEF Long Edge Feed
L/H Left Hand
LJ Left Jetstack
LPR Line Printer Remote
LTR Letter size paper (8.5 x 11 inches)
LSI Large Scale Integrated Circuit
mA Mili-amp
MAC Address Media Access Control Address
MARKDWR Marking Drawer/Unit
MB Mega Byte
MHz Mega Hertz
MM Millimeter
MOSFET Metal-Oxide Field-Effect Transistor
MOT Motor
MP Media Path
MPT Multi-Purpose Tray
NA North America
NBNS NetBIOS Name Service
NCL Nest Configuration Library
NetBIOS Network Basic Input/ Output System
NOHAD Noise, Ozone, Heat, Air, Dust
NPP No Paper
NVM Non Volatile Memory
NVRAM Non-Volatile Random Access Memory
OCR Optical Character Recognition
OEM Original Equipment Manufacturer
OHP Over Head Paper (Transparency)
OPT Optional
OS Operating System
PC Personal Computer
PCB Printed Circuit Board
PCL Printer Command Language
PEST Print Engine Self Test
PDF Adobe Acrobat Portable Document Format
PDL Page Description Language
PH Preheater
P/J Plug Jack (electrical connections)
Table 1 Acronyms and Abbreviations
Acronyms/
Abbreviations
Description

Xerox COLORQUBE 8570 Specifications

General

Print Technology	Solid Ink
Monthly Duty Cycle	Up to 85, 000 pages
First Page Out Time (Color)	As fast as 5 seconds
First Page Out Time (B&W)	As fast as 5 seconds
Memory (Maximum)	1 GB
Output Capacity	350 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 40 ppm color / 40 ppm black
Connectivity	USB 2.0, Ethernet
Print Languages	PCL 6, PostScript 3, PDF
