Repairs and Adjustments
Phaser 3435 5/08 4-13
5. Remove the two screws securing the Input Guide and remove it.
Figure 4
6. Unplug the connector from the Input Guide and remove the one screw securing the Thermis-
tor and remove it.
Figure 5
Input guide
Thermistor
