Yanmar 4JH4E - Special Hand Tools

4. Disassembly and reassembly
125
4.2.2 Special hand tools
Name of tool Illustration Remarks
Piston pin insertion/
extraction tool
Extraction of piston pin
Insertion of piston pin
Connecting rod
small end bushing
insertion/extraction
tool for 3JH4E /
4JH4TE
Extraction
Connecting rod
small end bushing
insertion/extraction
tool for 4JH4-TE /
4JH4-HTE
Extraction
A
BC
D
006943-01X
mm
ABCD
12 20 80 25
011221-00X
011222-00X
B
C
A
D
010365-00X
mm
ABCD
25.4-25.7 20 80 28.4-28.7
010364-00X
010363-00
X
A
BC
D
E
F
ABC D E F
31
-0.2
-0.5
80 20
28
-0.45
-0.48
45±0.5 9°±30°
001404-00X
