Yanmar 4JH4E - Bilge Pump and Bilge Strainer (Optional); Introduction

9. Coolant system
278
9.7 Bilge pump and bilge strainer (Optional)
9.7.1 Introduction
(1) General Introduction
(2) Exterior
Name Bilge pump
Time 10 minutes
Rotation direction Right (viewed from the impeller side)
Weight Pump 1.4 kg
Negative pressure detector Diaphragm type
Temperature -30°C-80°C
Pump dimensions
Length 225 mm
Yoke diameter Ø61
Assembly hole diameter Ø5.3
Assembly pitch 50 x 90 mm
Green
Red
Red (+)
White (-)
White
Controller
Battery
Blue
Motor assy
Inlet
Strainer
Outlet
001591-01E
