14. Tightening torque for bolts and nuts
327
14. Tightening torque for bolts and nuts
14.1 Main bolt and nut
14.2 Standard bolts and nuts (without lube oil)
No. Name
Thread diameter
x pitch (mm)
Lubricating oil application
(thread portion, and seat
surface)
Tor qu e
Nm (kgf-m)
1 Head bolt M10 x 1.25 Coat with lube oil 85.2-91.2 (8.69-9.30)
2 Rod bolt M9 x 1.0 Coat with lube oil 44.1-49.1 (4.50-5.01)
3 Flywheel bolt M10 x 1.25 Coat with lube oil 83.3-88.3 (8.49-9.00)
4 Metal cap bolt M12 x 1.5 Coat with lube oil 96-100 (9.79-10.2)
5
Crankshaft pulley bolt
(FC300 pulley)
M14 x 1.5 Coat with lube oil 83.2-93.2 (8.48-9.50)
6 Nozzle retainer bolt M8 x 1.25 No lube oil 24.4-28.4 (2.49-2.90)
7 Fuel injection pump gear nut
3/4JH4E
M14 x 1.5
No lube oil 78-88 (8-9)
4JH4-TE
4JH4-HTE
Coat with lube oil 59-69 (6-7)
8 Fuel injection pipe joint nut M12 x 1.5 No lube oil 29.4-34.4 (3.00-3.51)
9 Heat exchanger set bolt M8 x 1.25 No lube oil 34.2-40.2 (3.49-4.10)
10
Starter relay terminal nut
(Magnetic relay)
M6 x 1.0 No lube oil 3.0-4.2 (0.31-0.43)
Nm (kgf-m)
Name Screw dia. x pitch (mm) Tightening torque Remarks
Hexagon bolt with a "7"
head and hexagon nut.
("7" mark means JIS
strength classification
"7T".)
M6 x 1 9.8-11.8 (1.0-1.2) Apply 80% torque when
tightening to aluminum
alloy.
Apply 60% torque to 4T
bolts and lock nuts.
(4T bolt has no mark on
the head.)
M8 x 1.25 22.5-28.5 (2.3-2.9)
M10 x 1.5 44-54 (4.5-5.5)
M12 x 1.75 78.2-98.2 (8.0-10.0)
PT plug (Taper plug) 1/8 9.8 (1.0)
1/4 19.6 (2.0)
3/8 29.4 (3.0)
1/2 58.8 (6.0)
Pipe joint bolt M8 12.7-16.7 (1.3-1.7)
M10 19.5-25.5 (2.0-2.6)
M12 24.4-34.4 (2.5-3.5)
M14 39.1-49.1 (4.0-5.0)
M16 48.9-58.9 (5.0-6.0)
