12. Electrical system
305
12.4.2 Structure
(1) Disassembly drawing
(2) Structure
Front bracket
Rotor
Stator
Fan
Ball bearing
Rear bracket assembly
Pulley
011065-00E
12V60A alternator
Bracket
Nut
Stator
assembly
Rectifier
assembly
Rotor
assembly
Through bolt
Nut M5
Rotative direction
Ball bearing
Packing
Bracket
Pulley
011066-00SE
