Yanmar 4JH4E - Structure

12. Electrical system
309
12.5.2 Structure
Disassembly drawing and structure
Fan
Front cover
Bearing retainer
Stator
Brush
regulator assy
Diode
Condenser
Rotor
Ball bearing
Spacer
Pulley
Capacitor assembly
Rear cover
Brush regulator
assembly
Brush holder
Diode assembly
Screw (M5 x 0.8 x14)
Bearing retainer
Front cover
assembly
Stator assembly Rotor assembly Brush assembly
IC regulator
assembly
Ball bearing
Pulley nut assembly
Spacer
Pulley assembly
Rear cover assembly
Through
bolt
Brush set
Ball bearing
Rear cover
Insulating
bushing
011070-00SE
