11. Remote control system (Optional)
295
11.3 Remote control inspection
(1) When the control lever movement does
not coincide with operation of the
engine, check the cable end stop nut to
see whither or not it is loose, and
readjust/retighten when necessary.
(2) Too many bends (turns) in the cable or
bends at too extreme and angle will
make it difficult to turn the handle.
Reroute the cable to reduce the number
of bends of enlarge the bending radius
as much as possible (to 200 mm or
more).
(3) Check for loose cable bracket/clamp
bolts or nuts and retighten as necessary.
(4) Check cable connection screw heads,
cable sleeves and other metal parts for
rust or corrosion. Clean off minor rust
and wax or grease the parts. Replace if
the parts are heavily rusted or corroded.
Throttle Throttle
Reverse
Free throttle
Neutral
Shim in
Shim in
Forward
010664-00E
