6. Fuel Injection equipment
215
6. Fuel Injection equipment
6.1 Fuel Injection pump/governor
for 3JH4E and 4JH4E
Refer to the JH3E manual of separate volume for
the disassembly and assembly, adjustment
procedure of a fuel injection pump.
6.1.1 Fuel system diagram
Fuel injection
pump
Feed pump
Fuel nozzle
Fuel injection pipe
Fuel return
pipe
Fuel filter
From fuel tank
Water separator
To fuel tank
010555-00E
