Yanmar 4JH4E - Air Heater (Optional)

12. Electrical system
315
12.8 Air heater (Optional)
An air heater is available for warming intake air
when starting in a cold weather. The air heater is
mounted to the intake manifold. The device is
operated by the glow switch on the instrument
panel.
3JH4E/4JH4E 4JH4-TE/4JH4-HTE
Part No. 129120-77501 129100-77500
Rated output 390W
Rated current 35.5A
Rated voltage DC11V
Relay
Air heater
Gasket
Intake manifold
Wire harness
011084-00E
2-M6 x 1
terminal
010666-01E
78
78
60
5
60
Max. 106
9
18
010667-01X
3JH4E and 4JH4E
4JH4-TE and 4JH4-HTE
