4. Disassembly and reassembly
134
16 Rotation
gauge
Contact type Measures rotation speed by using a
reflector seal which is placed on the
exterior of the revolving shaft.
Photoelectric
type
Measures rotation speed by using a
reflector seal which is placed on the
exterior of the revolving shaft.
High pressure
fuel pipe clamp
type
Measures rotation speed without
reference to revolving shaft center or
the exterior of the revolving shaft.
17 Circuit tester Measure the resistance, voltage,
and continuity of the electric circuit.
No. Name of tool Use Illustration
001443-00X
Revolving shaft
Reflection mark
001444-00E
High pressure pipe
001445-00E
007232-00X
