4. Disassembly and reassembly
155
(38) Removing the crankshaft
1) Remove the crankshaft.
Note:
1) The thrust metal (upper) is mounted to the
standard main bearing.
2) Remove the main bearing metal (upper)
from the cylinder block.
(39) Removing the tappets
Remove the tappets from the tappet holes in the
cylinder block.
Note:
1) Be careful to keep all disassembled parts in
order.
2) Clear and adequate area for parts and
prepare a container.
3) Prepare a cleaner and cleaning can before
disassembling start.
010432-00X
010429-00X
010434-00
