11. Remote control system (Optional)
293
(2) Clutch control
Neutral
S1 S2
Clamp
To engine speed To marine gear
Reverse Forward
Remote control head
010661-00E
Bolt (M8 x 25)
Bolt (M8 x 25)
Shims
Stopper bolt
Oil seal
Lock nut
Bolt
Split pin
Washer
Shift lever
Pivot
Cable clamp
010662-00SE
KM35P marine gear
Note: ( ) Cable shift travel
S1 = More than 36 mm (1.42")
S2 = More than 36 mm (1.42")
