13. Service standards
323
(4) Piston and ring
1) Piston
mm
Inspection item Standard Limit
Reference
page
Piston outside diameter
(Measure in the direction
vertical to the piston pin.)
3JH4E 87.950-87.960 87.900
5.3.1(2)
4JH4E 87.935-87.945 87.885
4JH4-TE/ 4JH4-HTE 83.930-83.940 83.880
Clearance between
piston and cylinder
3JH4E 0.045-0.075 -
4JH4E 0.06-0.090 -
4JH4-TE/ 4JH4-HTE 0.065-0.095 -
Piston diameter measure position
(Upward from the bottom end of the piston)
22 -
3JH4E
4JH4E
Piston pin hole inside
diameter
26.000-26.009 26.020
5.3.2
Piston pin outside
diameter
25.995-26.000 25.965
Clearance between
piston pin and hole
0.000-0.014 0.074
4JH4-TE
4JH4-HTE
Piston pin hole inside
diameter
28.000-28.009 28.020
Piston pin outside
diameter
27.995-28.000 27.965
Clearance between
piston pin and hole
0-0.014 0.074
