YASKAWA HV600 User Manual

Parameter Details
5
5.11 S: Special Applications
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 393
Table 5.62 AUTO Run Command Behavior when b1-01 = 7 to 9
AUTO Command
External Run
(Terminal, Serial, or Option)
AUTO LED
*1
Drive Operation Description HOA State
No No OFF No
• Drive Stopped
• Drive is in OFF Mode
OFF
Yes No OFF No
• Drive is in AUTO Mode
• Waiting for Run command
AUTO
No Yes OFF No
• Drive received the Run command
• Waiting for AUTO command
OFF
Yes Yes ON Yes Drive is operating in AUTO Mode AUTO
Yes Yes
Long Blink
(50% duty)
No
• Drive is in Sleep Mode
• Output Frequency is 0 or drive
decelerates to STOP
AUTO
Yes Yes Double Blink No
Waiting for cycle of commands
Example:
• Drive Ready condition was removed
• Drive starts Fast-Stop operation
AUTO
*1 The LED is available when o2-24 ≠ 2 [LED Light Function Selection ≠ Keypad LED Light Disable].
By default, the drive will energize in AUTO Mode. When you de-energize the drive in AUTO Mode while S5-10 = 1
[AUTO Key Memory at Power Down = Enabled], the drive will memorize the press and it will energize in
AUTO Mode again. When you de-energize the drive in HAND or OFF Mode, the drive will energize in OFF Mode.
Note:
If you set b1-02 = 0 [Run Command Selection 1 = Keypad] and S5-10 = 2 [AUTO Mode] at the same time, the drive detects oPE05 [Run
Cmd/Freq Ref Source Sel Err].
■ HAND Command
You can input the HAND Command from:
• when S5-07 = 1 [Operation HAND Key = Enabled]
• One of MFDI terminals set for:
– H1-xx = 6E [HAND Command]
– H1-xx = 6D [AUTO Command] when S5-04 = 0 [HAND-OFF-AUTO Behavior = Legacy]
When S5-04 = 0, the drive will receive the HAND Command when the MFDI set for H1-xx = 6E is activated, or
when the MFDI set for H1-xx = 6D is OFF and the drive receives a Run command.
Note:
The drive will disable when o2-02 = 0 [OFF Key Function Selection = Disabled] and b1-02 ≠ 0 [Run Command Selection 1 ≠
Keypad].
HAND Command
External Run
(Terminal, Serial, or
Option)
HAND LED
*1
Drive Operation HOA Mode Description HOA State
No No OFF No
Normal
Legacy
• Drive Stopped
• Drive is in OFF Mode
OFF
Yes No OFF No Legacy
HAND Mode ready but No Run
command
HAND
Yes Yes ON Yes Legacy Drive is operating in HAND Mode HAND
Yes Yes
Long Blink
(50% duty)
No Legacy
Output Frequency is 0 or drive
decelerates to STOP
HAND
Yes Yes Double Blink No Legacy
Waiting for cycle of commands
Example:
• Drive Ready condition was
removed
• Drive starts Fast-Stop operation
HAND
Yes Yes/No ON Yes Normal Drive is operating in HAND Mode HAND
