YASKAWA HV600 User Manual

Parameter Details
5
5.14 Z: Bypass Parameters
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 449
4: K4 Motor 1 Contactor
Setting Value Function Description
4 K4 Motor 1 Contactor Set when the K4 contactor is closed.
5: K5 Motor 2 Contactor
Setting Value Function Description
5 K5 Motor 2 Contactor Set when the K5 contactor is closed.
6: READY
Setting Value Function Description
6 READY System ready.
7: RUN Active
Setting Value Function Description
7 RUN Active Drive run or bypass run active.
8: Drive RUN active
Setting Value Function Description
8 Drive RUN active The digital output activates when the system is in Drive Mode and the HV600 drive is running.
ON : Running in Drive Mode
OFF : Not running or in Bypass Mode
Note:
This output stays active during Energy Savings Mode Z1-16 = 1, 2 [Energy Savings Mode = Frequency, Frequency + Current.
9: Bypass RUN active
Setting Value Function Description
9 Bypass RUN active The digital output activates when the system is in Bypass Mode and is running. Contactor K3 is closed.
ON : Running in Bypass Mode
OFF : Not running or in Drive Mode
Note:
This output stays active during Energy Savings Mode Z1-16 = 1, 2 [Energy Savings Mode = Frequency, Frequency + Current.
10: HAND mode Active
Setting Value Function Description
10 HAND mode Active The digital output activates when the system is running in HAND Mode during Drive Mode and Bypass Mode.
ON : Running in HAND Mode
OFF : Not running or in AUTO Mode
11: OFF mode Active
Setting Value Function Description
11 OFF mode Active The digital output activates when the HAND/OFF/AUTO selection is in OFF Mode or if system is faulted. It is also active when in
Emergency Override Mode.
ON : System is in OFF Mode or is faulted
OFF : HAND Mode, AUTO Mode (even if not running), Emergency Override.
12: Auto mode Active
Setting Value Function Description
12 Auto mode Active The digital output activates when the HAND/OFF/AUTO selection is in AUTO Mode. It will activate when the system is running
and when the system is not running and in Drive Mode and Bypass Mode.
ON : System is in AUTO Mode
OFF : HAND Mode, OFF Mode, Faulted, Emergency Override
