YASKAWA HV600 User Manual

Troubleshooting
6
6.3 Faults, Minor Faults, Alarms, and Error Codes Listed Alphabetically
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 461
Display (Hex.) Name ALM LED Type Ref.
EF (0007) FWD/REV Run Command Input Error Flashing Alarm 500
EF0 (001A) Option Card External Fault Flashing Alarm 500
EF0 (0027) Option Card External Fault Illuminated Drive Fault 478
EF1 (0039) External Fault (Terminal S1) Flashing Alarm 500
EF1 (0042) External Fault (Terminal S1) Illuminated Drive Fault 478
EF2 (003A) External Fault (Terminal S2) Flashing Alarm 500
EF2 (0043) External Fault (Terminal S2) Illuminated Drive Fault 478
EF3 (0009) External Fault (Terminal S3) Flashing Alarm 500
EF3 (0011) External Fault (Terminal S3) Illuminated Drive Fault 478
EF4 (000A) External Fault (Terminal S4) Flashing Alarm 500
EF4 (0012) External Fault (Terminal S4) Illuminated Drive Fault 479
EF5 (000B) External Fault (Terminal S5) Flashing Alarm 500
EF5 (0013) External Fault (Terminal S5) Illuminated Drive Fault 479
EF6 (000C) External Fault (Terminal S6) Flashing Alarm 500
EF6 (0014) External Fault (Terminal S6) Illuminated Drive Fault 479
EF7 (000D) External Fault (Terminal S7) Flashing Alarm 501
EF7 (0015) External Fault (Terminal S7) Illuminated Drive Fault 479
End1 Excessive Rated Voltage Setting Flashing An Auto-Tuning Error 513
End2 Iron Core Saturation Coefficient Flashing An Auto-Tuning Error 513
End3 Rated Current Setting Alarm Flashing An Auto-Tuning Error 513
End4 Adjusted Slip Calculation Error Flashing An Auto-Tuning Error 513
End5 Resistance Tuning Error Flashing An Auto-Tuning Error 513
End6 Leakage Inductance Alarm Flashing An Auto-Tuning Error 513
End7 No-Load Current Alarm Flashing An Auto-Tuning Error 513
EOF (0067) Emergency Override FWD Flashing Alarm 501
EOR (0068) Emergency Override REV Flashing Alarm 501
EP24v (0081) External Power 24V Supply Flashing Alarm 501
Er-01 Motor Data Error Flashing An Auto-Tuning Error 513
Er-02 Drive in an Alarm State Flashing An Auto-Tuning Error 514
Er-03 STOP Button was Pressed Flashing An Auto-Tuning Error 514
Er-04 Line-to-Line Resistance Error Flashing An Auto-Tuning Error 514
Er-05 No-Load Current Error Flashing An Auto-Tuning Error 514
Er-08 Rated Slip Error Flashing An Auto-Tuning Error 514
Er-09 Acceleration Error Flashing An Auto-Tuning Error 515
Er-12 Current Detection Error Flashing An Auto-Tuning Error 515
Er-13 Leakage Inductance Error Flashing An Auto-Tuning Error 515
Er-18 Back EMF Error Flashing An Auto-Tuning Error 515
Er-25 HighFreq Inject Param Tuning Err Flashing An Auto-Tuning Error 515
Err (001F) EEPROM Write Error Illuminated Drive Fault 479
FAn1 (0413) Drive Cooling Fan Fault Illuminated Drive Fault 479
FB02 (043A) Wait For Interlock Timeout Illuminated System Fault 480
FB03 (043B) External Fault Bypass (EFB) Illuminated System Fault 480
FB05 (043D) Motor Overload Illuminated System Fault 480
