6.3 Faults, Minor Faults, Alarms, and Error Codes Listed Alphabetically
460 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Display (Hex.) Name ALM LED Type Ref.
CPF02 (0083) A/D Conversion Error Illuminated Drive Fault 473
CPF03 (0084) Control Board Connection Error Illuminated Drive Fault
473
CPF06 (0087) EEPROM Memory Data Error Illuminated Drive Fault 474
CPF07 (0088) Terminal Board Connection Error Illuminated Drive Fault 474
CPF08 (0089) Terminal Board Connection Error Illuminated Drive Fault 474
CPF11 (008C) RAM Fault Illuminated Drive Fault 474
CPF12 (008D) FLASH Memory Fault Illuminated Drive Fault 474
CPF13 (008E) Watchdog Circuit Exception Illuminated Drive Fault 474
CPF14 (008F) Control Circuit Fault Illuminated Drive Fault 474
CPF16 (0091) Clock Fault Illuminated Drive Fault 475
CPF17 (0092) Timing Fault Illuminated Drive Fault 475
CPF18 (0093) Control Circuit Fault Illuminated Drive Fault 475
CPF19 (0094) Control Circuit Fault Illuminated Drive Fault 475
CPF20 (0095) Control Circuit Error Illuminated Drive Fault 475
CPF21 (0096) Control Circuit Error Illuminated Drive Fault 475
CPF22 (0097) Hybrid IC Error Illuminated Drive Fault 475
CPF23 (0098) Control Board Connection Error Illuminated Drive Fault 475
CPF24 (0099) Drive Unit Signal Fault Illuminated Drive Fault 476
CPF26 (009B) BB Circuit Error Illuminated Drive Fault 476
CPF27 (009C) PWM Set Reg Error Illuminated Drive Fault 476
CPF28 (009D) PWM Pattern Error Illuminated Drive Fault 476
CPF29 (009E) On-Delay Error Illuminated Drive Fault 476
CPF30 (009F) BB On Error Illuminated Drive Fault 476
CPF31 (00A0) ASIC Code Error Illuminated Drive Fault 476
CPF32 (00A1) ASIC Startup Error Illuminated Drive Fault 476
CPF33 (00A2) Watch-dog Eror Illuminated Drive Fault 477
CPF34 (00A3) Power/Clock Eror Illuminated Drive Fault 477
CPF35 (00A4) Ext A/D Conv Error Illuminated Drive Fault 477
CPF36 (00A5) ASIC COM Error Illuminated Drive Fault 477
CPF37 (00A6) ASIC COM Error Illuminated Drive Fault 477
CPF38 (00A7) EEPROM Data Error Illuminated Drive Fault 477
CPF39 (00A8) CPU-ASIC Communication Error Illuminated Drive Fault 477
CPyE Error Writing Data - Backup Function Runtime Error 516
CrST Cannot Reset Flashing Not an alarm. 499
CSEr Control Mode Mismatch - Backup Function Runtime Error 516
CyPo (0029) Cycle Power to Accept Changes Flashing Alarm 499
dEv (0011) Speed Deviation Flashing Alarm 499
dEv (0019) Speed Deviation Illuminated Drive Fault 477
dFPS Drive Model Mismatch - Backup Function Runtime Error 516
DIFF (0093) Differential Feedback Exceeded Flashing Alarm 499
DIFF (0421) Differential Feedback Exceeded Illuminated Drive Fault 478
dnE (002A) Drive Disabled Flashing Alarm 499
dv7 (005B) Polarity Judge Timeout Illuminated Drive Fault 478
