9.5 b: Application
600 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
No.
(Hex.)
Name Description
Default
(Range)
Ref.
b3-17
(01F0)
Expert
Speed Est Retry Current
Level
Sets the current level for the search retry function in Speed Estimation Speed Search as a
percentage where drive rated current is a setting value of 100%.
110%
(0 - 200%)
204
b3-18
(01F1)
Expert
Speed Est Retry
Detection Time
Sets the length of time that the drive will wait to retry Speed Estimation Speed Search
when too much current flow stopped the Speed Search.
0.10 s
(0.00 - 1.00 s)
204
b3-19
(01F2)
Speed Search Restart
Attempts
Sets the number of times to restart Speed Search if Speed Search does not complete. 3 times
(0 - 10 times)
204
b3-24
(01C0)
Speed Search Method
Selection
Sets the Speed Search method when you start the motor or when you return power after a
momentary power loss.
Note:
Set b3-24 = 1. If b3-24 = 2, the drive will detect oPE08 [Parameter Selection Error].
1 : Speed Estimation
2 : Current Detection 2
2
(1, 2)
204
b3-25
(01C8)
Expert
Speed Search Wait Time Sets the length of time the drive will wait to start the Speed Search Retry function. 0.5 s
(0.0 - 30.0 s)
205
b3-26
(01C7)
Expert
Direction Determination
Level
Sets the level to find the motor rotation direction. Increase the value if the drive cannot
find the direction.
1000
(40 to 60000)
205
b3-27
(01C9)
Expert
Speed Search RUN/BB
Priority
Sets the conditions necessary to start Speed Search.
0 : SS Only if RUN Applied Before BB
1 : SS Regardless of RUN/BB Sequence
0
(0, 1)
205
b3-31
(0BC0)
Expert
Spd Search Current
Reference Lvl
Sets the current level that decreases the output current during Current Detection Speed
Search.
1.50
(1.50 - 3.50)
205
b3-32
(0BC1)
Expert
Spd Search Current
Complete Lvl
Sets the current level that completes Speed Search. 1.20
(0.00 - 1.49)
205
b3-33
(0B3F)
Expert
Speed Search during Uv
Selection
Sets the function that starts Speed Search at start-up if the drive detects a Uv
[Undervoltage] when it receives a Run command.
0 : Disabled
1 : Enabled
1
(0, 1)
206
b3-56
(3126)
InverseRotationSearch
WaitTime
Sets the wait time until the drive starts inverse rotation search after it completes forward
search when you do inverse rotation search during Current Detection Speed Search.
Determined by o2-04
(0.1 - 5.0 s)
206
â—† b4: Timer Function
No.
(Hex.)
Name Description
Default
(Range)
Ref.
b4-01
(01A3)
Timer Function ON-
Delay Time
Sets the ON-delay time for the timer input. 0.0 s
(0.0 - 3000.0 s)
207
b4-02
(01A4)
Timer Function OFF-
Delay Time
Sets the OFF-delay time for the timer input. 0.0 s
(0.0 - 3000.0 s)
207
b4-03
(0B30)
Expert
Terminal M1-M2 ON-
Delay Time
Sets the delay time to activate the contact after the function set in H2-01 activates. 0 ms
(0 - 65000 ms)
207
b4-04
(0B31)
Expert
Terminal M1-M2 OFF-
Delay Time
Sets the delay time to deactivate the contact after the function set in H2-01 deactivates. 0 ms
(0 - 65000 ms)
207
b4-05
(0B32)
Expert
Terminal M3-M4 ON-
Delay Time
Sets the delay time to activate the contact after the function set in H2-02 activates. 0 ms
(0 - 65000 ms)
207
b4-06
(0B33)
Expert
Terminal M3-M4 OFF-
Delay Time
Sets the delay time to deactivate the contact after the function set in H2-02 deactivates. 0 ms
(0 - 65000 ms)
207
