9.10 H: Terminal Functions
616 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H1-76
(39F0)
RUN
Terminal S6 Off-Delay
Time
Sets the length of time necessary for Terminal S6 to be open before the drive removes the
programmed function.
0.00 s
(0.00 - 300.00 s)
264
H1-77
(39F1)
RUN
Terminal S7 Off-Delay
Time
Sets the length of time necessary for Terminal S7 to be open before the drive removes the
programmed function.
0.00 s
(0.00 - 300.00 s)
264
â– H1-xx: MFDI Setting Values
Setting Value Function Description Ref.
3 Multi-Step Speed
Reference 1
Uses speed references d1-01 to d1-08 to set a multi-step speed reference. 264
4 Multi-Step Speed
Reference 2
Uses speed references d1-01 to d1-08 to set a multi-step speed reference. 264
5 Multi-Step Speed
Reference 3
Uses speed references d1-01 to d1-08 to set a multi-step speed reference. 265
6 Jog Reference Selection Sets the drive to use the JOG Frequency Reference (JOG command) set in d1-17 [Jog Reference]. The JOG Frequency
Reference (JOG command) overrides the d1-01 to d1-08 [References 1 to 8] settings.
265
7 Accel/Decel Time
Selection 1
Sets the drive to use Acceleration/Deceleration Time 1 [C1-01, C1-02] or Acceleration/Deceleration Time 2 [C1-03,
C1-04].
265
8 Baseblock Command (N.
O.)
Sets the command that stops drive output and coasts the motor to stop when the input is ON.
ON : Baseblock (drive output stop)
OFF : Normal operation
265
9 Baseblock Command (N.
C.)
Sets the command that stops drive output and coasts the motor to stop when the input terminal is OFF.
ON : Normal operation
OFF : Baseblock (drive output stop)
265
A Accel/Decel Ramp Hold Momentarily pauses motor acceleration and deceleration when the terminal is turned ON, retains the output frequency
that was stored in the drive at the time of the pause, and restarts motor operation.
266
B Overheat Alarm (oH2) Sets the drive to display an oH2 [Drive Overheat Warning] alarm when the input terminal is ON. The alarm does not
have an effect on drive operation.
266
C Analog Terminal Enable
Selection
Sets the command that enables or disables the terminals selected in H3-14 [Analog Input Terminal Enable Sel].
ON : Input to the terminal selected with H3-14 is enabled
OFF : Input to the terminal selected with H3-14 is disabled
266
F Not Used Use this setting for unused terminals or to use terminals in through mode. 266
14 Fault Reset Sets the command to reset the current fault when the Run command is inactive.
Note:
The drive ignores the fault reset command when the Run command is active. Remove the Run command before
trying to reset a fault.
266
15 Fast Stop (N.O.) Sets the command to ramp to stop in the deceleration time set in C1-09 [Fast Stop Time] when the input terminal is
activated while the drive is operating.
266
17 Fast Stop (N.C.) Sets the command to ramp to stop in the deceleration time set in C1-09 [Fast Stop Time] when the input terminal is
activated while the drive is operating.
267
18 Timer Function Sets the command to start the timer function. Use this setting with Timer Output [H2-xx = 12]. 267
19 PID Disable Sets the command to disable PID control when b5-01 = 1 or 3 [PID Mode Setting = Standard or Fref + PID Trim].
ON : PID control disabled
OFF : PID control enabled
267
1B Programming Lockout Sets the command to prevent parameter changes when the terminal is OFF.
ON : Programming Lockout
OFF : Parameter Write Prohibit
267
1E Reference Sample Hold Sets the command to sample the frequency reference at terminals A1 or A2 and hold the frequency reference at that
frequency.
268
20 External Fault (NO-
Always-Ramp)
When the terminal activates, the drive ramps to stop in the selected deceleration time. Fault relay output terminal MA-
MC will turn ON, and MB-MC will turn OFF. The drive always detects external faults whether the drive is stopped or
running.
268
21 External Fault (NC-
Always-Ramp)
When the terminal deactivates, the drive ramps to stop in the selected deceleration time. Fault relay output terminal
MA-MC will turn ON, and MB-MC will turn OFF. The drive always detects external faults whether the drive is
stopped or running.
268
22 External Fault (NO-
@Run-Ramp)
When the terminal activates during run, the drive ramps to stop in the selected deceleration time. Fault relay output
terminal MA-MC will turn ON, and MB-MC will turn OFF. The drive does not detect external faults while the drive is
stopped.
268
