9.10 H: Terminal Functions
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 617
Setting Value Function Description Ref.
23 External Fault (NC-
@Run-Ramp)
When the terminal deactivates during run, the drive ramps to stop in the selected deceleration time. Fault relay output
terminal MA-MC will turn ON, and MB-MC will turn OFF. The drive does not detect external faults while the drive is
stopped.
268
24 External Fault (NO-
Always-Coast)
When the terminal activates, the drive shuts off the output and the motor coasts to stop. Fault relay output terminal
MA-MC will turn ON, and MB-MC will turn OFF. The drive always detects external faults whether the drive is
stopped or running.
268
25 External Fault (NC-
Always-Coast)
When the terminal deactivates, the drive shuts off the output and the motor coasts to stop. Fault relay output terminal
MA-MC will turn ON, and MB-MC will turn OFF. The drive always detects external faults whether the drive is
stopped or running.
268
26 External Fault (NO-
@Run-Coast)
When the terminal activates during run, the drive shuts off the output and the motor coasts to stop. Fault relay output
terminal MA-MC will turn ON, and MB-MC will turn OFF. The drive does not detect external faults while the drive is
stopped.
268
27 External Fault (NC-
@Run-Coast)
When the terminal deactivates during run, the drive shuts off the output and the motor coasts to stop. Fault relay output
terminal MA-MC will turn ON, and MB-MC will turn OFF. The drive does not detect external faults while the drive is
stopped.
268
28 External Fault (NO-
Always-FStop)
When the terminal activates, the drive stops the motor in the deceleration time set to C1-09 [Fast Stop Time]. Fault
relay output terminal MA-MC will turn ON, and MB-MC will turn OFF. The drive always detects external faults
whether the drive is stopped or running.
268
29 External Fault (NC-
Always-FStop)
When the terminal deactivates, the drive stops the motor in the deceleration time set to C1-09 [Fast Stop Time]. Fault
relay output terminal MA-MC will turn ON, and MB-MC will turn OFF. The drive always detects external faults
whether the drive is stopped or running.
268
2A External Fault (NO-
@Run-FStop)
When the terminal activates during run, the drive stops the motor in the deceleration time set to C1-09 [Fast Stop
Time]. Fault relay output terminal MA-MC will turn ON, and MB-MC will turn OFF. The drive does not detect
external faults while the drive is stopped.
268
2B External Fault (NC-
@Run-FStop)
When the terminal deactivates during run, the drive stops the motor in the deceleration time set to C1-09 [Fast Stop
Time]. Fault relay output terminal MA-MC will turn ON, and MB-MC will turn OFF. The drive does not detect
external faults while the drive is stopped.
268
2C External Fault (NO-
Always-Alarm)
When the terminal activates, the keypad shows EFx [External Fault (Terminal Sx)] and the output terminal set for
Alarm [H2-01 to H2-03 = 10] activates. The drive continues operation. The drive always detects external faults
whether the drive is stopped or running.
268
2D External Fault (NC-
Always-Alarm)
When the terminal deactivates, the keypad shows EFx [External Fault (Terminal Sx)] and the output terminal set for
Alarm [H2-01 to H2-03 = 10] activates. The drive continues operation. The drive always detects external faults
whether the drive is stopped or running.
268
2E External Fault (NO-
@Run-Alarm)
When the terminal activates during run, the keypad shows EFx [External Fault (Terminal Sx)] and the output terminal
set for Alarm [H2-01 to H2-03 = 10] activates. The drive continues operation. The drive does not detect external faults
while the drive is stopped.
268
2F External Fault (NC-
@Run-Alarm)
When the terminal deactivates during run, the keypad shows EFx [External Fault (Terminal Sx)] and the output
terminal set for Alarm [H2-01 to H2-03 = 10] activates. The drive continues operation. The drive does not detect
external faults while the drive is stopped.
268
30 PID Integrator Reset Sets the command to reset and hold the PID control integral to 0 when the terminal is ON. 269
31 PID Integrator Hold Sets the command to hold the integral value of the PID control while the terminal is activated. 269
34 PID Soft Starter Disable Sets the PID soft starter function.
ON : No
OFF : Yes
269
35 PID Input (Error) Invert Sets the command to turn the terminal ON and OFF to switch the PID input level (polarity). 269
3E PID Setpoint Selection 1 Sets the function to switch the PID setpoint to YA-02 [Setpoint 2] or YA-04 [Setpoint 4]. Set this function and H1-xx =
3F [PID Setpoint Selection 2] at the same time.
Note:
If you use this function and one of H1-xx = 83 to 85 [Dedicated Multi-Setpoint YA-02 to YA-04] at the same time,
the drive will detect an oPE03 [Multi-Function Input Setting Err].
ON : YA-02 or YA-04 is PID setpoint.
OFF : The frequency reference, YA-01 [Setpoint 1], or YA-03 [Setpoint 3] is PID setpoint.
270
3F PID Setpoint Selection 2 Sets the function to switch the PID setpoint to YA-03 [Setpoint 3] or YA-04 [Setpoint 4]. Set this function and H1-xx =
3E [PID Setpoint Selection 1] at the same time.
Note:
If you use this function and one of H1-xx = 83 to 85 [Dedicated Multi-Setpoint YA-02 to YA-04] at the same time,
the drive will detect an oPE03 [Multi-Function Input Setting Err].
ON : YA-03 or YA-04 is PID setpoint.
OFF : The frequency reference, YA-01 [Setpoint 1], or YA-02 [Setpoint 2] is PID setpoint.
270
40 Forward RUN (2-Wire) This function will not operate in a bypass system.
Sets the Forward Run command for 2-wire sequence 1.
ON : Forward Run
OFF : Run Stop
270
44 Add Offset Frequency 1
(d7-01)
Sets the function to add the offset frequency set in d7-01 [Offset Frequency 1] to the frequency reference when the
terminal activates.
270
45 Add Offset Frequency 2
(d7-02)
Sets the function to add the offset frequency set in d7-02 [Offset Frequency 2] to the frequency reference when the
terminal activates.
270
