YASKAWA HV600 User Manual

9.10 H: Terminal Functions
618 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Setting Value Function Description Ref.
46 Add Offset Frequency 3
(d7-03)
Sets the function to add the offset frequency set in d7-03 [Offset Frequency 3] to the frequency reference when the
terminal activates.
270
51 Sequence Timer Disable Sets the command to disable Sequence Timers.
ON : Sequence Timer is Disabled
271
52 Sequence Timer Cancel Sets the command to cancel the currently active Sequence Timer.
ON : Cancel Active Sequence Timer
271
61 Speed Search from Fmax Sets the function to start speed search using an external reference although b3-01 = 0 [Speed Search Selection at Start
= Disabled].
Note:
The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 61 and 62 are set at the same time.
271
62 Speed Search from Fref Sets the function to use an external reference to start speed search although b3-01 = 0 [Speed Search Selection at Start
= Disabled].
Note:
The drive will detect oPE03 [Multi-Function Input Setting Err] when H1-xx = 61 and 62 are set at the same time.
271
63 Field Weakening Sets the function to send the Field Weakening Level and Field Weakening Frequency Limit commands set in d6-01
[Field Weakening Level] and d6-02 [Field Weakening Frequency Limit] when the input terminal is activated.
271
68 High Slip Braking (HSB)
Activate
Sets the command to use high-slip braking to stop the motor. 271
6A Drive Enable Sets the function to show dnE [Drive Enabled] on the keypad and ignore Run commands when the terminal is OFF. 272
70 Drive Enable 2 Sets the function to show dnE [Drive Enabled] on the keypad and ignore Run commands when the terminal is OFF.
ON : Run command is accepted.
OFF : Run command is disabled. When the drive is running, it stops according to b1-03 setting.
272
82 PI Switch to Aux Sets YF-xx [PI Auxiliary Control] parameters as primary PI loop parameters and disables b5-xx [PID Control].
Note:
When this input is active, YF-xx [PI Auxiliary Control] parameters will always be the primary PI loop parameters.
Parameter YF-20 [PI Aux Main PI Speed Control] does not have an effect.
272
83 Dedicated Multi-Setpoint
YA-02
Sets the function to set the PID setpoint to YA-02 [Setpoint 2].
Note:
If you use this function and one of H1-xx = 3E or 3F [PID Setpoint Selection 1 or 2] at the same time, the drive
will detect an oPE03 [Multi-Function Input Setting Err].
ON : YA-02 is PID setpoint.
OFF : YA-01 [Setpoint 1], YA-03 [Setpoint 3], or YA-04 [Setpoint 4] is PID setpoint.
272
84 Dedicated Multi-Setpoint
YA-03
Sets the function to set the PID setpoint to YA-03 [Setpoint 3]. Set this function and H1-xx = 83 [Dedicated Multi-
Setpoint YA-02] at the same time.
Note:
If you use this function and one of H1-xx = 3E or 3F [PID Setpoint Selection 1 or 2] at the same time, the drive
will detect an oPE03 [Multi-Function Input Setting Err].
ON : YA-03 is PID setpoint.
OFF : YA-01 [Setpoint 1], YA-02 [Setpoint 2], or YA-04 [Setpoint 4] is PID setpoint.
272
85 Dedicated Multi-Setpoint
YA-04
Sets the function to set the PID setpoint to YA-04 [Setpoint 4]. Set this function, H1-xx = 83 [Dedicated Multi-Setpoint
YA-02], and H1-xx = 84 [Dedicated Multi-Setpoint YA-03] at the same time.
Note:
If you use this function and one of H1-xx = 3E or 3F [PID Setpoint Selection 1 or 2] at the same time, the drive
will detect an oPE03 [Multi-Function Input Setting Err].
ON : YA-04 is PID setpoint.
OFF : YA-01 [Setpoint 1], YA-02 [Setpoint 2], or YA-03 [Setpoint 3] is PID setpoint.
273
88 Thermostat Fault Sets the drive to show the VLTS [Thermostat Fault] when the input terminal is ON.
Note:
This function is active when the drive is running.
273
A8 PI2 Control Disable Sets the command to disable the PI2 Control function. Parameter S3-12 [PI2 Control Disable Mode Sel] sets the
output performance.
ON : Enabled
OFF : Disabled
273
AA PI2 Control Inverse
Operation
Sets the command to change the sign of the PI2 Control input. 273
AB PI2 Control Integral Reset Sets the command to reset the PI2 Control integral value.
Note:
This input has priority over H1-xx = AC [MFDI Function Selection = PI2 Control Integral Hold].
273
AC PI2 Control Integral Hold Sets the command to lock the PI2 Control integral value. 273
