YASKAWA HV600 User Manual

Network Communications
10
10.4 APOGEE FLN (P1) Communications
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 723
Point
No.
Point
Type
Point Name
Factory
Default
(SI Units)
Eng. Units
(SI Units)
Slope
(SI Units)
Intercept
(SI Units)
On Text Off Text Parameter
56 LAO REF OP MODE 1 - 1 0 - - b1-01
57 LAO OPER DISP MD 0 - 1 0 - - o1-03
58
*1
LDI MF IN 1 MON OFF - 1 0 ON OFF UB-02 (bit 2)
59
*1
LDI MF IN 2 MON OFF - 1 0 ON OFF UB-02 (bit 3)
60
*1
LAO INPUT REF 1 0 Hz 0.01 0 - - -
61 LAO INPUT REF 2 0 Hz 0.01 0 - - d1-02
62
*1
LAI PID FEEDBACK 0 % 0.01 0 - - U5-01
63 LAO PID P GAIN 2 - 0.01 0 - - b5-02
64 LAO PID I TIM 1 s 0.1 0 - - b5-03
65 LDO PID MODE SEL DISABLE - 1 0 ENABLE DISABLE b5-01
66
*1
LAI LST FLT CODE 0 - 1 0 - - U2-02
67
*1
LAI FREF FLT 0 Hz 0.01 0 - - U2-03
68
*1
LAI OUT FREQ FLT 0 Hz 0.01 0 - - U2-04
69
*1
LAI OUT CUR FLT 0 A 0.01/0.1 0 - - U2-05
70 LAO RD PARAM NUM 1 - 1 0 - - -
71 LAI RD PARAM DAT 0 - 1 0 - - -
72 LAO WR PARAM NUM 1 - 1 0 - - -
73 LAO WR PARAM DAT 0 - 1 0 - - -
74
*1
LDI MF IN 3 MON OFF - 1 0 ON OFF UB-02 (bit 4)
75
*1
LAI OUT VOLT FLT 0 V 0.1 0 - - U2-07
76
*1
LAI DC BUS FLT 0 V 1 0 - - U2-08
77
*1
LAI OUT PWR FLT 0 kW 0.1 0 - - U2-09
78
*1
LDI MF IN 4 MON OFF - 1 0 ON OFF UB-02 (bit 5)
79
*1
LAI PID DEVIATE 0 % 0.01 0 - - U5-02
80 LAO PID I LIMIT 100 % 0.1 0 - - b5-04
81 LAO PID UP LIMIT 100 % 0.1 0 - - b5-06
82 LAO PID OFFS ADJ 100 % 0.1 -100 - - b5-07
83 LAO PID PRI DYTM 0 s 0.1 0 - - b5-08
84 - N/A - - - - - - -
85 - N/A - - - - - - -
86 - N/A - - - - - - -
87
*1
LAI PID OUT CAP 0 % 0.01 0 - - U5-14
88
*1
LAI PID REF 0 % 0.01 0 - - U5-04
89
*1
LAI COMM ERR CD 0 - 1 0 - - U1-19
90 LDO COMM FLT ENA DISABLE - 1 0 ENABLE DISABLE H5-05
91 LAO CBL LOSS FREQ 0 Hz 0.01 0 - - H5-34
92 LAO CBL LOSS TMR 2 s 0.1 0 - - H5-09
93
*1
LDI OK.FAULT OK - 1 0 FAULT OK UB-06 (bit 2)
94
*1
LDO RESET FAULT NO - 1 0 RESET NO -
95
*1
LDI DRV COMM ERR NO FLT - 1 0 FAULT NO FLT -
96
*1
LDO EXTERNAL FLT OK - 1 0 FAULT OK -
97
*1
LDI MF IN 5 MON OFF - 1 0 ON OFF UB-02 (bit 6)
