YASKAWA HV600 User Manual

10.4 APOGEE FLN (P1) Communications
722 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Point
No.
Point
Type
Point Name
Factory
Default
(SI Units)
Eng. Units
(SI Units)
Slope
(SI Units)
Intercept
(SI Units)
On Text Off Text Parameter
16
*1
LAI RUN TIMEX10K 0 10kh 1 0 - - U4-01
17
*1
*1
LAI FAULT CODE 0 - 1 0 - - U2-01
18
*1
LDI MINOR FLT NO FLT - 1 0 FAULT NO FLT UB-05 (bit 8)
19
*1
LDI MAJOR FLT NO FLT - 1 0 FAULT NO FLT UB-06 (bit 2)
20 - N/A - - - - - - -
21
*1
LDI FWD.REV FWD - 1 0 REV FWD U1-12 (bit 2)
22
*1
LDO CMD.REV.STOP STOP - 1 0 REV STOP -
23
*1
LDI RUN.STOP STOP - 1 0 RUN STOP UB-06 (bit 1)
24
*1
LDO CMD.RUN.STOP STOP - 1 0 FWD STOP -
25
*1
LDI ZERO SPEED OFF - 1 0 ON OFF U1-12 (bit 1)
26
*1
LDI SPEED AGREE NO AGR - 1 0 AGREE NO AGR U1-12 (bit 4)
27
*1
LDI DRIVE READY NOTRDY - 1 0 READY NOTRDY -
28
*1
LDI LOC.REM MON REMOTE - 1 0 LOCAL REMOTE UB-05 (bit 0)
29
*1
- N/A - - - - - - -
30 LAO CURRENT LIM 0 A 0.01/0.1 0 - - E2-01
31 LAO ACCEL TIME 1 0 s 0.1 0 - - C1-01
32 LAO DECEL TIME 1 0 s 0.1 0 - - C1-02
33 LDO LOCK PANEL UNLOCK - 1 0 LOCK UNLOCK -
34 - N/A - - - - - - -
35
*1
LDO RUN ENABLE STOP - 1 0 ENABLE STOP -
36 LAO STALL PRE RN 115 % 1 5 - - L3-06
37 LAO STALL PRE AC 120 % 1 0 - - L3-02
38 LAO FREQ UP LIM 100 % 0.1 0 - - d2-01
39 LAO FREQ LOW LIM 0 % 0.1 0 - - d2-02
40
*1
LDI MULTI OUT 1 OFF - 1 0 ON OFF UB-03 (bit 6)
41
*1
LDI MULTI OUT 2 OFF - 1 0 ON OFF UB-03 (bit 7)
42
*1
LDI MULTI OUT 3 OFF - 1 0 ON OFF UB-03 (bit 8)
43
*1
LDI SAFETY ILOCK OFF - 1 0 ON OFF UB-05 (bit 7)
44
*1
LDO MF INP 1 OFF - 1 0 ON OFF -
45
*1
LDO MF INP 2 OFF - 1 0 ON OFF -
46
*1
LDO MF INP 3 OFF - 1 0 ON OFF -
47
*1
LDO MF INP 4 OFF - 1 0 ON OFF -
48
*1
LDO MF INP 5 OFF - 1 0 ON OFF -
49 LAO JUMP FREQ 1 0 Hz 0.1 0 - - d3-01
50 LAO JUMP FREQ 2 0 Hz 0.1 0 - - d3-02
51 LAO JUMP FREQ 3 0 Hz 0.1 0 - - d3-03
52 LAO JUMP FREQ BW 0 Hz 0.1 0 - - d3-04
53 LAO
NUM
AUTOSTRT
0 - 1 0 - - L5-01
54 LAO POWER LOSS RT 0.1 s 0.1 0 - - L2-02
55 LAO RUN OP MODE 7 - 1 0 - - b1-02
