168 HB700 | CPU | PMC921xEx | en | 24-04
Deployment CPU iC921xM-FSoE
iC9200 Series
System variables and status information > System variables
Diagnostic status register
SPLC.DIAG.ST
ATUS_REG.
xxx
NOTICE
The warning threshold for CPU load is 70%, the switch-off threshold is 90%. If
the 90% CPU load is exceeded, the safety CPU switches of
f.
The following table describes the information of the bits (0 ... 15) in the diagnostic
status register (SPLC.DIAG.ST
ATUS_REG.xxx).
System variable/elements Type - description
SPLC SPNSV2_TYPE - Data structure
DIAG
STATUS_REG
DBG
2
BOOL - Non-safe debug operation of the safety CPU.
The safety CPU is in one of the two DEBUG states (DEBUG-
RUN or DEBUG-ST
OP/DEBUG-HALT).
EST BOOL - There is an entry in the error memory of the safe oper-
ating system (error stack) of the safety CPU. Diagnostic and error
messages from the safe operating system of the safety CPU are
available.
These messages can be read and analyzed via iCube Engineer.
The variable always has the value TRUE if at least one entry is
contained in the error memory of the safety operating system.
As soon as the error memory was read via iCube Engineer and
thus cleared, the value of the variable changes to F
ALSE.
FS BOOL - Failure state of the safety CPU.
An error was detected that puts the safety CPU in fail safe state.
‘Fail safe states’...page 130
In this state, the associated, more detailed error code is con-
tained in the diagnostic parameter registers of the safety CPU
(SPLC.DIAG.P
ARAM_REG and SPLC.DIAG.PARAM_2_REG).
INIT
1
BOOL - Initialization of the safety CPU.
The initialization of the safety CPU firmware (safe operating
system) was completed without errors.
IO
1
BOOL - Initialization of the safety I/O channel communication.
The initialization of the FSoE communication to the I/O devices
was completed without errors.
PON
1
BOOL - PowerON process.
The safety CPU is powered. The firmware was loaded into the
RAM memory of the safety CPU and booted up. The self-test
routines of the safety CPU were completed without errors.
POST BOOL - PowerON self-test of the safety CPU (POWER ON SELF
TEST).
Self-test of the safety CPU active after PowerON.
PRO
1
BOOL - Load and start the safety application program.
The safety-related application programme created with iCube
Engineer
was loaded into the safety operating system of the
safety CPU and started without errors.
