80 HB700 | CPU | PMC921xEx | en | 24-04
Technical data > iC9216M-FSoE - PMC9216ES
Order no. PMC9212ES
Net weight 488 g
Weight including accessories 503 g
Gross weight 621 g
Environmental conditions
Operating temperature 0 °C to 60 °C
Storage temperature -40 °C to 70 °C
Certifications
UL certification -
KC certification -
UKCA certification yes
ChinaRoHS certification yes
3.3.4 iC9216M-FSoE - PMC9216ES
Order no. PMC9216ES
Type iC9212M-EC
Module ID -
Technical data power supply
Power supply (rated value) DC 24 V
Power supply (permitted range) DC 20.4...28.8 V
Reverse polarity protection
ü
Current consumption (no-load operation) 0.2 A
Current consumption (rated value) 1.5 A
Inrush current 1 A
I²t 0.3 A²s
Max. current drain at backplane bus 3 A
Max. current drain load supply -
Power loss 12 W
Hardware
CPU Triton (ARM A17)
CPU cores 3
Frequency 1.26 GHz
RAM 2 GB
eMMC 8 GB
Operating controls LEDs, Three-point switch, DIP-switches
Integrated SliceBus supply
ü
Connectors
