180 HB700 | CPU | PMC921xEx | en | 24-04
Web-based management - WBM
Diagnostics > PROFINET - optional
Tab: ‘Overview
’
■ Severity
– Here you can limit the message entries based on their severity.
– The limitation is based on the following graduation for the minimum severity:
Internal à Information à W
arning à Error à Critical Error à Fatal Error
For example with Internal, all degrees of severity are listed. With the setting Error,
all Error, Critical Error and Fatal Error are listed.
■ Sender
– Here you can limit the message entries by entering or selecting a sender in the
selection field.
– The currently list of message entries is always decisive for the names in the
selection field.
– When entering a name or part of the name, click on [Apply Filter] to list messages
from senders that match or partially match the name you are looking for
.
■ Maximum number of notifications
– Here you can limit the number of message entries to be listed.
– 1024 is set by default, a maximum of 4000 is allowed.
■ Time from, Time to
– Here you can limit the period of the message entries by entering the date and time.
– Time from: Lists all message entries that are not older than the specified time.
– Time to: Lists all message entries that are older than the specified time.
– When filtering by time specification, a date must always be entered and a time can
be added.
6.3.5 PROFINET - optional
Here you will find information on the current PROFINET function of the controller and its
IP settings.
Please note that a separate licence is required for the use of PROFINET
,
which must be activated accordingly!
Profinet
Diagnostics
Overview ...
Information
Configuration
Security
Administration
iC92...
PMC92...
Diagnostics
Axis Grid
EtherCAT
Motion Alarms
Notifications
Profinet
SliceBus
SliceBus Modules
