HB700 | CPU | PMC921xEx | en | 24-04 19
Approvals, directives, standards
1.17 Approvals, directives, standards
Conformity and approval
Conformity
CE 2014/30/EU EMC Directive
2006/42/EC Machinery Directive
RoHS (EU) 2011/65/EU Restriction of the use of certain hazardous substances
UKCA 2016 No. 1091 Electromagnetic Compatibility Regulations
2008 No. 1597 Supply of Machinery (Safety) Regulation
RoHS (UK) 2012 No. 3032 Use of Certain Hazardous Substances
Protection of persons and device protection
Type of protection - IP20
Electrical isolation
to the field bus - electrically isolated
to the process level - electrically isolated
Insulation resistance EN 61131-2 -
Insulation voltage to reference earth
Inputs / outputs - AC / DC 50V, test voltage AC 500V
Protective measures - against short circuit
Environmental conditions to EN 61131-2
Climatic
Storage / transport EN 60068-2-14 -40…+70°C
Operation
Horizontal installation hanging EN 61131-2 0…+60°C
Vertical installation EN 61131-2 0…+55°C
Air humidity EN 60068-2-30 RH1 (without condensation, rel. humidity 10…95%)
Pollution EN 61131-2 Degree of pollution 2
Installation altitude max. - 2000m
Mechanical
Oscillation EN 60068-2-6 1g, 9Hz ... 150Hz
Shock EN 60068-2-27 15g, 11ms
Mounting conditions
Mounting place - In the control cabinet (IP54 or better)
Mounting position - Horizontal hanging ⮫
‘Assembly possibilities’...page 32
