YASKAWA iC9200 Series

HB700 | CPU | PMC921xEx | en | 24-04 69
iC9200 Series
Hardware description
Technical data > iC9212M-EC - PMC9212E0
3.3 Technical data
3.3.1 iC9212M-EC - PMC9212E0
Order no. PMC9212E0
Type iC9212M-EC
Module ID -
Technical data power supply
Power supply (rated value) DC 24 V
Power supply (permitted range) DC 20.4...28.8 V
Reverse polarity protection
ü
Current consumption (no-load operation) 0.2 A
Current consumption (rated value) 1.5 A
Inrush current 1 A
I²t 0.3 A²s
Max. current drain at backplane bus 3 A
Max. current drain load supply -
Power loss 12 W
Hardware
CPU Triton (ARM A17)
CPU cores 3
Frequency 1.26 GHz
RAM 2 GB
eMMC 8 GB
Operating controls LEDs, Three-point switch, DIP-switches
Integrated SliceBus supply
ü
Connectors
Serial Com (Sub-D) -
SliceBus
ü
Number of RJ45 interfaces 4 Ports
External SD card
External SD card
ü
Operating system
Operating system Linux with RT Kernel
Overlay filesystem on internal eMMC
ü
Overlay filesystem on internal eMMC, Capacity 1500 MB
Overlay filesystem on external SD card
ü
Overlay filesystem on external SD card, Capacity depending on SD card
Firewall
ü
