1.7 H: Terminal Functions
YASKAWA ELECTRIC SIEP C710606 10A YASKAWA AC Drive - V1000 PRELIM. Programming Manual 171
Parameter Details
1
Setting 3D: During Speed Search
Output terminal closes while Speed Search is being performed. Refer to b3: Speed Search
on page 50 for details on the Speed Search function.
Setting 3E: PID Feedback Low
Output terminal closes when a PID feedback loss is detected. The feedback is considered to
be lost if it falls below the level set to b5-13 for longer than the time set to b5-14. Refer to
PID Feedback Loss Detection on page 67 for details.
Setting 3F: PID Feedback High
Output terminal closes when a PID feedback loss is detected. The feedback is considered to
be lost if it rises beyond the level set to b5-36 for longer than the time set to b5-37. Refer to
PID Feedback Loss Detection on page 67 for details.
Setting 4A: During KEB Operation
Output terminals closes while KEB is being performed. Refer to KEB Function on
page 194 for a KEB function description.
Setting 4B: During Short Circuit Braking
Closes the output terminal while Short Circuit Braking is being executed.
Setting 4C: During Fast Stop
Output terminal closes when a Fast Stop is being executed. Refer to C1-09: Fast Stop Time
on page 79 for details.
Setting 4D: oH Pre-Alarm Time Limit
Output terminal closes when the drive is reducing the speed due to a drive overheat alarm
(L8-02 = 4) and the overheat alarm has not disappeared after ten frequency reduction
operation cycles. Refer to L8-03: Overheat Alarm Operation Selection on page 217 for
details.
