1.11 Auto-Tuning
YASKAWA ELECTRIC SIEP C710606 10A YASKAWA AC Drive - V1000 PRELIM. Programming Manual 245
Parameter Details
1
◆ Auto-Tuning Interruption and Fault Codes
If tuning results are abnormal or the STOP key is pressed before completion, Auto-Tuning
will be interrupted and a fault code will be displayed on the digital operator.
Figure 1.87
Figure 1.87 Auto-Tuning Interruption Display
◆ Performing Auto-Tuning
■ Auto-Tuning Procedure
Auto-Tuning should generally be performed in the following steps.
1. Follow the instructions mentioned in Before Auto-Tuning the Drive on page 243.
2. Determine which type of Auto-Tuning best fits the application requirements following
Figure 1.88.
A – Normal Auto-Tuning Display B – Auto-Tuning Interrupted
AB
To Next Page
