1.7 H: Terminal Functions
Parameter Details
1
1.7 H: Terminal Functions
H parameters are used to assign functions to the external terminals.
◆ H1: Multi-Function Digital Inputs
■ H1-01 to H1-06: Functions for Terminals S1 to S6
These parameters assign functions to the multi-function digital inputs. The settings 0 to 9F
determine function for each terminal and are explained below.
Note: If not using an input terminal or if using the through-mode, set that terminal to “F”.
Table 1.40 Digital Multi-Function Input Settings
No.
<1> Number appearing in parenthesis is the default value after performing a 3-wire initialization.
Parameter Name
Setting
Range
Default
H1-01 Digital Input S1 Function Selection 1 to 9F 40: Forward Run Command (2-wire sequence)
H1-02 Digital Input S2 Function Selection 1 to 9F 41: Reverse Run Command (2-wire sequence)
H1-03 Digital Input S3 Function Selection 0 to 9F 24: External Fault
H1-04 Digital Input S4 Function Selection 0 to 9F 14: Fault Reset
H1-05 Digital Input S5 Function Selection 0 to 9F 3 (0) <1>: Multi-Step Speed Reference 1
H1-06 Digital Input S6 Function Selection 0 to 9F 4 (3) <1>: Multi-Step Speed Reference 2
Setting Function Page Setting Function Page
0 3-Wire Sequence 140 31 PID Integral Hold 151
1 LOCAL/REMOTE Selection 141 32 Multi-Step Speed Reference 4 151
2 External Reference 1/2 142 34 PID Soft Starter Cancel 151
3 Multi-Step Speed Reference 1
142
35 PID Input Level Selection 151
4 Multi-Step Speed Reference 2 40 Forward Run/Stop (2-wire sequence)
151
5 Multi-Step Speed Reference 3 41 Reverse Run/Stop (2-wire sequence)
6 Jog Reference Selection 142 42 Run/Stop (2-wire sequence 2)
152
7 Accel/Decel Time 1 142 43 FWD/REV (2-wire sequence 2)
8 Baseblock Command (N.O.)
142
44 Offset Frequency 1 Addition
152
9 Baseblock Command (N.C.) 45 Offset Frequency 2 Addition
A Accel/Decel Ramp Hold 143 46 Offset Frequency 3 Addition
B Drive Overheat Alarm (OH2) 144 60 DC Injection Braking Command 152
C Terminal A2 Enable 144 61 External Speed Search Command 1
153
F Not used (through mode) 144 62 External Speed Search Command 2
