YASKAWA OYMC V1000

1.6 F: Option Settings
138 YASKAWA ELECTRIC SIEP C710606 10A YASKAWA AC Drive - V1000 PRELIM. Programming Manual
■ F7-17 to F7-22: EtherNet Scaling Factors
These parameters define scaling factors for drive monitors in the EtherNet Class ID 2AH -
AC Drive Object.
Setting
The monitor value in the Class 2AH - AC Drive Object is calculated by:
Class 2AH Object Monitor = Drive Value x 2
Scaling
Example:
If the drive output frequency monitor (U1-02) is 50.0 and the scaling is set to F7-17 = 3, then
the value in the Class 2AH - AC Drive Object, Instance 1, Attribute 7 would be 500 x 2
3
=
4000.
<1> Valid from drive firmware version 1011 and later. Parameter number was F7-21 in older software.
No. Parameter Name Setting Range Default
F7-17 <1>
<1> Valid from drive firmware version 1011 and later.
EtherNet Speed Scaling -15 to 15 0
F7-18 <1> EtherNet Current Scaling -15 to 15 0
F7-19 <1> EtherNet Torque Scaling -15 to 15 0
F7-20 <1> EtherNet Power Scaling -15 to 15 0
F7-21 <1> EtherNet Voltage Scaling -15 to 15 0
F6-22 <1> EtherNet Time Scaling -15 to 15 0
