9.2 List of Parameters
9.2.2 List of Parameters
9-39
9
Parameter Lists
Pn635
2
Output Signal Selec-
tions 10
0000h to
6666h
– 0654h All
After
restart
Setup –
Pn636
2
Output Signal Selec-
tions 11
0000h to
0666h
– 0000h All
After
restart
Setup –
Continued on next page.
Continued from previous page.
Parameter
No.
Size
Name
Setting
Range
Setting
Unit
Default
Setting
Applicable
Motors
When
Enabled
Classi-
fication
Refer-
ence
n.X
/POUT0 (Programmable Output 0) Signal Allocation Reference
0 Disabled (the above signal output is not used).
page 6-5
1 Output the signal from the CN1-25 or CN1-26 output terminal.
2 Output the signal from the CN1-27 or CN1-28 output terminal.
3 Output the signal from the CN1-29 or CN1-30 output terminal.
4 Output the signal from the CN1-37 output terminal.
5 Output the signal from the CN1-38 output terminal.
6 Output the signal from the CN1-39 output terminal.
n.X
/POUT1 (Programmable Output 1) Signal Allocation Reference
0 to 6
The settings are the same as for /POUT0 (Programmable Output
0) Signal Allocation.
page 6-5
n.X
/POUT2 (Programmable Output 2) Signal Allocation Reference
0 to 6
The settings are the same as for /POUT0 (Programmable Output
0) Signal Allocation.
page 6-5
n.X
/POUT3 (Programmable Output 3) Signal Allocation Reference
0 to 6
The settings are the same as for /POUT0 (Programmable Output
0) Signal Allocation.
page 6-5
n.X
/POUT4 (Programmable Output 4) Signal Allocation Reference
0 Disabled (the above signal output is not used).
page 6-5
1 Output the signal from the CN1-25 or CN1-26 output terminal.
2 Output the signal from the CN1-27 or CN1-28 output terminal.
3 Output the signal from the CN1-29 or CN1-30 output terminal.
4 Output the signal from the CN1-37 output terminal.
5 Output the signal from the CN1-38 output terminal.
6 Output the signal from the CN1-39 output terminal.
n.X
/POSRDY (Homing Completed Output) Signal Allocation Reference
0 to 6
The settings are the same as for /POUT4 (Programmable Output
4) Signal Allocation.
page 6-5
n.X
/DEN (Positioning Reference Distribution Output) Signal Allocation Reference
0 to 6
The settings are the same as for /POUT4 (Programmable Output
4) Signal Allocation.
page 6-5
n.X Reserved parameter (Do not change.)
