8.1 Alarm Displays
8.1.3 INDEXER Alarm Displays and Troubleshooting
8-38
8.1.3
INDEXER Alarm Displays and Troubleshooting
INDEXER alarms and corrections for them are given in the following table.
Error
Number
Alarm
Number
Alarm Name Meaning Corrective Action
Servo-
motor
Stop
Method
Alarm
Reset
E19A A.EF9
Program Table
Checksum
Alarm
(Detected only
when control
power supply is
turned ON.)
The program table
stored in flash mem-
ory was not
recorded properly.
(This alarm can
occur if the control
power supply is
turned OFF while the
program table is
being saved or ini-
tialized.)
Initialize the pro-
gram table. (Fn063)
If the problem is not
solved, correct the
program table.
Gr.1
Available
*1
E1AA A.EF9
Program Table
Version
Unmatched
(Detected only
when control
power supply is
ON.)
The combination of
the firmware version
and the program
table version is
wrong.
Change the firm-
ware version.
Change the pro-
gram table version
to match the firm-
ware version.
Gr.1
Available
*1
E1BA A.EF9
Program Out-
of-range Alarm
(Detected only
when control
power supply is
turned ON.)
A value set in the
program table is not
within the allowed
setting range.
Change the firm-
ware version.
Change the pro-
gram table version
to match the firm-
ware version.
Gr.1
Available
*1
E1CA A.EF9
ZONE Table
Checksum
Alarm
(Detected only
when control
power supply is
turned ON.)
The ZONE table
stored in flash mem-
ory was not
recorded properly.
(This alarm can
occur if the control
power supply is
turned OFF while the
ZONE table is being
saved or initialized.)
Initialize the ZONE
table. (Fn064)
If the problem is not
solved, correct the
ZONE table.
Gr.1
Available
*2
E1DA A.EF9
ZONE Table
Version
Unmatched
(Detected only
when control
power supply is
turned ON.)
The combination of
the firmware version
and the ZONE table
version is wrong.
Change the firm-
ware version.
Change the ZONE
table version to
match the firmware
version.
Gr.1
Available
*2
E1EA A.EF9
ZONE Table
Out-of-range
Alarm
(Detected only
when control
power supply is
turned ON.)
A value set in the
ZONE table is not
within the allowed
setting range.
Change the firm-
ware version.
Change the ZONE
table version to
match the firmware
version.
Gr.1
Available
*2
Continued on next page.
