7.3 Program Table Operation
7.3.3 Program Table Configuration
7-12
7.3.3
Program Table Configuration
The program table is a table that contains programming. You can enter up to 256 program
steps.
The configuration of the program table is shown below. Each line in the table is called a pro-
gram step. The steps are managed with program step numbers 0 to 255.
Note: You can program up to 256 program steps. You can used input signals (/SEL0 to /SEL4) to select program
steps numbers 0 to 31.
Refer to the following section for details on the items that are set.
7.3.4
Settings in the Program Table
on page 7-13
PGM-
STEP
POS SPD RDST RSPD ACC DEC
POUT EVENT LOOP
NEXT
0
1
2
:::::::::::
255
After you edit the program table, save it to flash memory. Refer to the following section for the
operating procedure.
Saving the Program Table to Flash Memory in the SERVOPACK on page 7-24
If you turn OFF the power supply before you save the program table in flash memory, the values
that you set in the program table will be lost.
Note
