6.2 I/O Signal Allocations
6.2.1 Input Signal Allocations
6-3
6
Settings
6.2 I/O Signal Allocations
Functions are allocated to the pins on the I/O signal connector (CN1) in advance. You can
change the allocations and the polarity for some of the connector pins. Function allocations
and polarity settings are made with parameters.
This section describes the I/O signal allocations.
6.2.1 Input Signal Allocations
Changing Input Signal Allocations
 Input Signals That Can Be Allocated to CN1-40 to CN1-46
The input signals that you can allocate to the pins on the I/O signal connector (CN1) and the
related parameters are given in the following table.
• If you change the polarity of the /S-ON (SERVO ON Input) signal from the default setting, you
will not be able to turn OFF the main circuit power supply to the Servomotor if signal lines break
or other problems occur. If you change the polarity of this signal, verify operation and make
sure that no safety problems will exist.
• If you allocate two or more signals to the same input circuit, a logical OR of the inputs will be
used and all of the allocated signals will operate accordingly. This may result in unexpected
operation.
Input Signal Input Signal Name Parameter
/S-ON Servo ON Pn50A = n.X
/P-CON Proportional Control Pn50A = n.X
P-OT Forward Drive Prohibit Pn50A = n.X
N-OT Reverse Drive Prohibit Pn50B = n.X
/ARM-RST Alarm Reset Pn50B = n.X
/P-CL Forward External Torque Limit Pn50B = n.X
/N-CL Reverse External Torque Limit Pn50B = n.X
/SPD-D Motor Direction Pn50C = n.X
/SPD-A Internal Set Speed Selection Pn50C = n.X
/SPD-B Internal Set Speed Selection Pn50C = n.X
/C-SEL Control Selection Pn50C = n.X
/ZCLAMP Zero Camping Pn50D = n.X
/INHIBIT Reference Pulse Inhibit Pn50D = n.X
/G-SEL Gain Selection Pn50D = n.X
/P-DET Polarity Detection Pn50D = n.X
SEN Absolute Data Request Pn515 = n.X
/PSEL
Reference Pulse Input Multiplication
Switch
Pn515 = n.
X
FSTP Forced Stop Pn516 = n.X
/MODE 0/1
Mode Switch
Pn630 = n.

X
/START-STOP
Program Table Operation Start-Stop
Pn630 = n.

X

/HOME
Homing
Pn630 = n.

X

/PGMRES
Program Table Operation Reset
Pn630 = n.X

/SEL0
Program Step Selection Input 0
Pn631 = n.

X
/SEL1
Program Step Selection Input 1
Pn631 = n.

X

/SEL2
Program Step Selection Input 2
Pn631 = n.

X

/SEL3
Program Step Selection Input 3
Pn631 = n.X

