7.4 Jog Speed Table Operation
7.4.3 Jog Speed Table and Speed Selection Signals
7-45
7
Operation with Digital I/O
7.4.3
Jog Speed Table and Speed Selection Signals
You can register up to eight jog speeds in the jog speed table.
The /JOG0 to /JOG2 (Jog Speed Selection) signals are used to specify the jog speeds that are
registered in the jog speed table.
Note: 1: Signal is ON (active), 0: Signal is OFF (inactive).
Jog Speed Table Jog Speed Selection Signals
JSPD
Jog Speed
(1,000 reference units/min)
/JSPD2 /JSPD1 /JSPD0
0 ±nnnnnnnnn 0 0 0
1 ±nnnnnnnnn 0 0 1
2 ±nnnnnnnnn 0 1 0
3 ±nnnnnnnnn 0 1 1
4 ±nnnnnnnnn 1 0 0
5 ±nnnnnnnnn 1 0 1
6 ±nnnnnnnnn 1 1 0
7 ±nnnnnnnnn 1 1 1
