7.5 ZONE Outputs
7.5.3 SigmaWin+ Procedures
7-55
7
Operation with Digital I/O
7.5.3
SigmaWin+ Procedures
You use the SigmaWin+ to edit, write, and save the ZONE table.
Use the following flow.
Editing the ZONE Table
Displaying the ZONE Table Editing Dialog Box.
Select Edit ZONE Table from the menu bar of the Main Window of the SigmaWin+.
Details on the ZONE Table Editing Dialog Box
Editing the ZONE Table
Writing the ZONE Table
Saving the ZONE Table
Checking the Operation of the ZONE Table
Editing the ZONE Table on page 7-55
Writing the ZONE Table on page 7-57
Saving the ZONE Table on page 7-59
