Page #101 background imageLoading...
Page #101 background image
No. Parameter Name Default Setting
H2-03 Terminals P2 Function Selection 5: Frequency Detection 2
L2-03
Momentary Power Loss Minimum
Baseblock Time
0.3 s
L3-04
Momentary Power Loss Voltage Recovery
Ramp Time
0: Disabled
L4-01 Speed Agreement Detection Level 2.0 Hz
L4-02 Speed Agreement Detection Width 0.0 Hz
L6-01 Torque Detection Selection 1 8: UL3 at RUN - Fault
L6-02 Torque Detection Level 1 5%
L6-03 Torque Detection Time 1 0.5 s
L8-05 Input Phase Loss Protection Selection
1: Enabled
<1>
L8-07 Output Phase Loss Protection Selection 1: Enabled
L8-38 Carrier Frequency Reduction 1: Enabled below 6 Hz
L8-41 High Current Alarm Selection 1: Enabled (alarm is output)
<1> Disable L8-05 for single-phase models.
Table 4.14 Preset 6: User Parameters (A2-01 to A2-16):
No. Parameter Name No. Parameter Name
A1-02 Control Method Selection d1-02 Frequency Reference 2
b1-01 Frequency Reference Selection 1 d1-03 Frequency Reference 3
b6-01 Dwell Reference at Start E1-08 Middle Output Frequency Voltage
b6-02 Dwell Time at Start H2-01
Terminals MA, MB, and MC Function
Selection
C1-01 Acceleration Time 1 L1-01 Motor Overload Protection Selection
C1-02 Deceleration Time 1 L4-01 Speed Agreement Detection Level
C6-02 Carrier Frequency Selection L6-02 Torque Detection Level 1
d1-01 Frequency Reference 1 L6-03 Torque Detection Time 1
u
Notes on Controlling the Brake when Using Application
Preset 6
The frequency detection function is used for controlling the brake.
When an external Baseblock command is present while a Run command is active, the
frequency reference will be kept as long as the Run command is active. To avoid improper
brake operation make sure that frequency detection is set so that the brake does not open during
Baseblock (L4-07 = “0”, default).
4.5 Application Selection
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
101
4
Start-Up Programming
& Operation
