Low Voltage Wiring for Control Circuit Terminals
Wire low voltage wires with NEC Class 1 circuit conductors. Refer to national state or local
codes for wiring. The external power supply shall be a UL-Listed Class 2 power source or
equivalent.
Table C.7 Control Circuit Terminal Power Supply
Input / Output Terminal Signal Power Supply Specifications
Multi-function photocoupler
output
P1, P2, PC Requires class 2 power supply
Multi-function digital inputs S1, S2, S3, S4, S5, S6, S7, SC
Use the internal power supply of the drive.
Use class 2 for external power supply.
Multi-function analog inputs A1, A2, AC
Use the internal power supply of the drive.
Use class 2 for external power supply.
Pulse train input RP
Use the internal LVLC power supply of the
drive. Use class 2 for external power supply.
Pulse train output MP
Use the internal LVLC power supply of the
drive. Use class 2 for external power supply.
n
Drive Short-Circuit Rating
This drive has undergone the UL short-circuit test, which certifies that during a short circuit
in the power supply the current flow will not rise above 31,000 amps maximum at 240 V for
200 V class drives and 480 V for 400 V class drives.
• The MCCB and breaker protection and fuse ratings shall be equal to or greater than the
short-circuit tolerance of the power supply being used.
• Suitable for use on a circuit capable of delivering not more than 31,000 RMS symmetrical
amperes for 240 V in 200 V class drives (up to 480 V for 400 V class drives) motor overload
protection.
u
CSA Standards Compliance
Figure C.6 CSA Mark
C.2 UL and CSA Standards
218
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
