Table C.6 Factory Recommended Drive Branch Circuit Protection
Drive Model
CIMR-Vo
Non-Time Delay
Class T Fuse Type
(Manufacturer: Ferraz)
Rated Voltage:
600 Vac, 200 kAIR
Fuse Ampere
Rating (A)
Fuse Type
(Manufacturer:
Bussmann)
Rated Voltage:
500 Vac, 200 kAIR
Fuse Ampere
Rating (A)
200 V Class Single-Phase Drives
BA0001 A6T6 6 FWH-25A14F 25
BA0002 A6T10 10 FWH-25A14F 25
BA0003 A6T20 20 FWH-60B 60
BA0006 A6T40 40 FWH-80B 80
BA0010 A6T40 40 FWH-100B 100
BA0012 A6T50 50 FWH-125B 125
BA0018 A6T80 80 FWH-175B 175
200 V Class Three-Phase Drives
2A0001 A6T3 3 FWH-25A14F 25
2A0002 A6T6 6 FWH-25A14F 25
2A0004 A6T15 15 FWH-25A14F 25
2A0006 A6T20 20 FWH-25A14F 25
2A0010 A6T25 25 FWH-70B 70
2A0012 A6T25 25 FWH-70B 70
2A0020 A6T40 40 FWH-90B 90
2A0030 – – FWH-100B 100
2A0040 – – FWH-200B 200
2A0056 – – FWH-200B 200
2A0069 – – FWH-200B 200
400 V Class Three-Phase Drives
4A0001 A6T3 3 FWH-40B 40
4A0002 A6T6 6 FWH-40B 40
4A0004 A6T15 15 FWH-50B 50
4A0005 A6T20 20 FWH-70B 70
4A0007 A6T25 25 FWH-70B 70
4A0009 A6T25 25 FWH-90B 90
4A0011 A6T30 30 FWH-90B 90
4A0018 – – FWH-80B 80
4A0023 – – FWH-100B 100
4A0031 – – FWH-125B 125
4A0038 – – FWH-200B 200
C.2 UL and CSA Standards
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
217
C
Standards Compliance
