YASKAWA V1000 User Manual

No. Parameter Name No. Parameter Name
C1-01 Acceleration Time 1 − −
u
Setting 3: Exhaust Fan Application
Table 4.7 Exhaust Fan: Parameter Settings
No. Parameter Name Default Setting
A1-02 Control Method Selection 0: V/f Control
b1-04 Reverse Operation Selection 1: Reverse Prohibited
C6-01 Drive Duty Selection 1: Normal Duty
E1-03 V/f Pattern Selection 0FH
E1-07 Middle Output Frequency 30.0 Hz
E1-08 Middle Output Frequency Voltage 50.0 V
L2-01 Momentary Power Loss Operation Selection 1: Enabled
L3-04
Stall Prevention Selection during
Deceleration
1: Enabled
Table 4.8 Exhaust Fan: User Parameters (A2-01 to A2-16)
No. Parameter Name No. Parameter Name
b1-01 Frequency Reference Selection 1 E1-07 Middle Output Frequency
b1-02 Run Command Selection 1 E1-08 Middle Output Frequency Voltage
b1-04 Reverse Operation Selection E2-01 Motor Rated Current
b3-01 Speed Search Selection at Start H1-05
Multi-Function Digital Input Terminal
S5 Function Selection
C1-01 Acceleration Time 1 H1-06
Multi-Function Digital Input Terminal
S6 Function Selection
C1-02 Deceleration Time 1 H1-07
Multi-Function Digital Input Terminal
S7 Function Selection
E1-03 V/f Pattern Selection L5-01 Number of Auto Restart Attempts
4.5 Application Selection
98
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
