YASKAWA V1000 - Ip00;Open-Chassis

u
IP00/Open-Chassis
n
Three-Phase AC200 V CIMR-Vo2A0030A ~ 0069A
Three-Phase AC400 V CIMR-Vo4A0018A ~ 0038A
A
B
M
L
K
J
I
H
G
F
C
D
E
A – Fan cover
B – Cooling Fan
C – Mounting hole
D – Heatsink
E – Optional 24 VDC power
supply connector cover
F – Terminal board Refer to
Control Circuit Terminal
Block Functions on page
66
G – Bottom cover
H – Front cover screw
I – Front cover
J – Terminal cover
K – Comm port
L – LED operator Refer to
Using the Digital LED
Operator on page 82
M – Case
Figure 1.4 Exploded View of IP00/Open-Chassis Type Components
Three-Phase AC400 V CIMR-Vo4A0018A
1.2 Component Names
