u
IP20/NEMA Type 1 Enclosure
n
Single-Phase AC200 V CIMR-VoBA0001F ~ 0003F
Three-Phase AC200 V CIMR-Vo2A0001F ~ 0006F
A
B
C
D
E
F
G
H
I
J
K
L
N
O
M
A
Fan cover
<1>
B Mounting hole
C Heatsink
D Optional 24 V DC power
supply connector cover
E Terminal board Refer to
Control Circuit Terminal
Block Functions on page
66
F Bottom cover screws
G Rubber bushing
H Bottom front cover
I Front cover screws
J Front cover
K Comm port
L LED operator Refer to
Using the Digital LED
Operator on page 82
M Case
N Top cover
O
Cooling fan
<1>
Figure 1.5 Exploded View of IP20/NEMA Type 1 Components
Three-Phase AC200 V CIMR-Vo2A0006F
<1> The drives CIMR-VoBA0001F ~ 0003F and CIMR-Vo2A0001F ~ 0004F do not have a
cooling fan or a cooling fan cover.
1.2 Component Names
34
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
